Etsi en 300 086 V2.1.2 (2016-08)

Standard for land mobile service equipment with an internal or external RF connector.

//CONTACT us

Subscribe for Updates

About the ETSI 300 086 V2.1.2 (2016-08) standard

The ETSI 300 086 V2.1.2 (2016-08) standard covers the technical requirements for Radio equipment with an internal or external RF connector intended primarily for analogue speech. It applies to use in the land mobile service, operating on radio frequencies between 30 MHz and 1 GHz, with channel separations of 12,5 kHz, 20 kHz and 25 kHz, primarily intended for analogue speech.

Radiocommunications service frequency bands
Transmit	30MHz to 1000MHz
Receive	30MHz to 1000MHz

Table 1: Radiocommunications service frequency bands

The equipment comprises a transmitter and associated modulator and/or a receiver and associated demodulator. The types of equipment covered by the present document are as follows:

Base station (equipment fitted with an antenna connector, intended for use in a fixed location);
Mobile station (equipment fitted with an antenna connector, normally used in a vehicle or as a transportable); and
Those hand portable stations:
- Fitted with an antenna connector; or
- Without an external antenna connector but fitted with a permanent internal or a temporary internal 50 Ω Radio Frequency (RF) connector which allows access to the transmitter output and the receiver input.

(NOTE: Hand portable equipment without an external or internal RF connector and without the possibility of having a temporary internal 50 Ω RF connector is not covered by the present document (integral antenna equipment is covered by ETSI EN 300 296)).

TÜV SÜD is an EU Notified Body authorized to evaluate products for compliance with the requirements of the EU’s Radio Equipment Directive (2014/53/EU) and approve the use of the RED CE mark, and a Nationally Recognized Testing Laboratory for FCC testing and certification.

We can help you with all aspects of the ETSI 300 086 V2.1.2 testing requirements including:

Transmitter

Frequency Error
Transmitter Power (conducted)
Maximum Effective Radiated Power
Frequency Deviation

Adjacent and Alternate Channel Power
Unwanted Emissions in the Spurious Domain
Intermodulation Attenuation

Receiver

Maximum Usable Sensitivity (Conducted)
Maximum Usable Sensitivity (Field Strength)
Co-Channel Rejection
Adjacent Channel Selectivity

Spurious Response Rejection
Intermodulation Response Rejection
Blocking or Desensitization
Spurious Radiations

TÜV SÜD’s expertise ensures compliance, safety, and security

Our professional and technically qualified engineers are active in national and international technical committees for safety, EMC, EMF, and RF for wireless radio and WPT devices. This makes them well suited to provide you with valuable understanding of the latest standards and regulations to keep ahead of the competition.

We can provide a one-stop-shop solution for all types of radio frequency testing through our global network of accredited laboratories and a world-leading certification service. Our experts are always up to date with regulatory changes and can efficiently support you in meeting the relevant test and certification requirements.
