Scope of VW80000
Volkswagen VW80000 standard applies to electric, electronic and mechatronic components and systems for the use in motor vehicles up to 3,5 t. This Standard in the present issue is based on template LV 124, which was drawn up by representatives of automobile manufacturers: Audi AG, BMW AG, Daimler AG, Porsche AG, and Volkswagen AG.
Testing capabilities
TÜV SÜD ‘s vast experience and continuous monitoring control equipment is ready to assist your LIN, CAN, and discrete I/0 components through all of the VW80000 and LV 124 Testing Requirements.
View all testing requirements
- E-01 Long-term overvoltage
- E-02 Transient overvoltage
- E-03 Jump start
- E-05 Load Dump
- E-06 Superimposed alternating voltage
- E-07 Slow Decrease and increase of supply voltage
- E-08 Slow decrease , quick increase of supply voltage
- E-09 Reset Behavior
- E-10 Short interruptions
- E-11 Start pulses
- E12 Voltage curve with intelligent generator control
- E-13 Pin interruption
- E-14 Connector interruption
- E-15 Reverse Polarity
- E-16 Ground offset
- E-17 Short Circuit in signal circuit and load circuits
- E-18 Insulation resistance
- E-19 Closed-Circuit Current
- E-20 Dielectric strength
- E-21 Backfeeds
- E-22 Overcurrents
- M-01 Free fall
- M-02 Stone impact test
- M-03 Dust test
- M-04 Vibration test
- M-05 Mechanical shock
- M-06 Endurance shock test
- K-01 High/low temperature storage
- K-02 Incremental temperature test
- K-03 Low-temperature operation
- K-04 repainting temperature
- K-05 Temperature shock (component)
- K-06 Salt spray test with operation , exterior
- K-07 Salt spray test with operation, interior
- K-08 Humid heat cyclic
- K-09 Humid heat, cyclic (with frost)
- K-10 Water protection – IPX0 to IPX6K
- K-11 High pressure cleaning
- K-12 Temperature Shock with splash water
- K-13 Temperature Shock – immersion
- K-14 Humid Heat , constant
- K-15 Condensation test with electric assemblies
- K-16 Sun Radiation
- L-01 Life Test – mechanical/hydraulic endurance test
- L-02 Life test - high temperature endurance test
- L-03 Life test – temperature cycle test
Testing for the phase are completed in multiple test legs that encompass initial sample inspection and functional checks, electrical and EMC testing, environmental testing, corrosion, vibration and other mechanical testing. No matter which phase or test leg your component is in, TÜV SÜD can support it!
Addtional testing capabilities
TÜV SÜD has multiple locations with a wide range of capabilities to support your testing which include but are not limited to:
- Cyclic Corrosion
- Mechanical Terminal and Connector Testing
- Electrical Testing
- EMC Testing
- Wireless Testing
- Cross-section Analysis
- Digital Microscopy
- X-Ray
Accreditation
TÜV SÜD’s automotive, environmental and EMC labs are accredited to ISO 17025 and can help ensure your automotive electrical/electronic component, sub-assembly or systems comply with global OEM and industry standards.
Automotive testing
TÜV SÜD’s comprehensive testing and certification services ensure you comply with all major industry standards. Our global network of testing labs and industry experts use the latest industry methods to support all necessary OEM Design Verification Plan and Report (DVP&R) requirements for materials, durability, shock & vibration, electrical, and EMC performance testing. TÜV SÜD is your single source for testing and certification services that will accelerate your time to global markets.
In addition to meeting OEM requirements for automotive component testing and compliance, automotive testing ensures maximum safety for customers and protects brand reputation protection. Product testing can provide early detection of faults, enabling manufacturers to improve products and secure their reputation as a provider of quality components.
